Name: 1-5V Coplanar Pressure Transmitter for High Temperature Level and Flow Applications
Brand: Xi'an Xiyi Central Control Technology Co., Ltd.
SKU: 3051CA
Price: 500.00 USD
Availability: InStock

Home > products > Industrial Pressure Transmitters >

1-5V Coplanar Pressure Transmitter for High Temperature Level and Flow Applications

5V Coplanar Pressure Transmitter

High Temperature Coplanar Pressure Transmitter

Place of Origin:

China

Brand Name:

rosemount

Model Number:

3051CA

Request A Quote

Product Details

Warranty:

12 Months

Customized Support:

OEM, ODM

Product Name:

3051CA Pressure Transmitter

Measuring Medium:

Pressure, Level And Flow

Output Signal:

4-20 (mA)

Voltage:

1-5 (V)

MOQ:

Highlight:

5V Coplanar Pressure Transmitter

High Temperature Coplanar Pressure Transmitter

Payment & Shipping Terms

Minimum Order Quantity

1 pc

Price

$400.00 - $600.00/pieces

Delivery Time

7-14 days

Payment Terms

T/T

Supply Ability

100 pc 1 week

Oil-free Ceramic Sensor PMC71 For Measurement In Gases Or Liquids

Get Best Price

Digital Pressure Transmitter PMC51 New Intelligent Pressure Transmitter

Get Best Price

Endress Hauser Cerabar PMC 51 600psi Absolute Gauge Pressure Sensor

Get Best Price

Authentic New Deltabar PMC51B/PMP51/PMP55 Pressure Transmitter With Cheaper Price And High Quality

Get Best Price

Contact Now

Product Description

1-5V Coplanar Pressure Transmitter for High Temperature Level and Flow Applications

Confidently measure pressure and level with the Rosemount 3051 In-Line Pressure Transmitter. Engineered for 10-year installed stability and 0.04% of span accuracy, this industry-leading pressure transmitter provides you with the information necessary to run, control and monitor processes. Available with a graphical, back-lit display, Bluetooth® connectivity, and enhanced software capabilities designed to access the data you need faster than ever before.

Features

* In-line gage and absolute pressure measurements support up to 20,000 psi (1378,95 bar) for pressure or level solutions
* Application specific configuration allows you to transform your pressure transmitter into a level transmitter with volume
calculations
* Complete pressure or level assemblies are leak-tested and calibrated to reduce leak points up to 70% and simplify installation
* 10-year installed stability and 150:1 rangedown produce reliable measurements and wide application flexibility
* Bluetooth® wireless connectivity unlocks a far simpler process to perform maintenance and service tasks without the need for a
physical connection or separate configuration tool
* The graphical, back-lit display allows for easy operation in 8 different languages in all lighting conditions
* Loop Integrity and Plugged Impulse Line diagnostics detect electrical loop issues and plugged impulse piping before it impacts
the quality of the process for increased safety and reduced downtime
* Quick service buttons offer built-in configuration buttons for streamlined commissioning
* SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
* Wireless Features * WirelessHART® technology is secure and cost-effective and delivers >99% data reliability
* SmartPower™ module provides up to 10-year maintenance-free operation and field replacement without
transmitter removal
* Easy installation enables quick instrumentation of measurement points without the cost of wiring

Item	Data
Brand Name	3051GP
Product Name	Pressure Transducer
Output signal	4-20mA+HART
Accuracy	1-5: +/-0.075% of span
Pressure type	Guage Pressure G
Range	0~61bar...600bar
Selling Units	Single item
Mounting	Coplanar and Traditional flanges and Adapters: Cadmium and Nickel-plated CS, 316 SST
Materials	Sensor Wetted Parts: SST, Hastelloy, Monel, Tantalum, Gold Plated SS, Gold Plated Monel
Power	4-20 mA: 10.5-55 V dc with no load Low Power: 6-12 V dc with no load
Output	4-20 mA with digital signal based on HART Protocol; Low Power, 1-5 V dc with digital signal based on HART Protocol; Low power, 0.8-3.2 V dc with digital signal based on HART Protocol, optional

FAQ

Q: How long will you give me the reply?

A: We will contact you within 2 working days.

Q: What is the delivery time?

A: Our delivery time is within 3-7 working days after we get the payment; for large qty mass order the time should be confirmed again for you.

Q: How about your package?

A: Do not worry about the package, we have rich experience at packing, all our package is standard exporting package.

Q: How about the payment terms?

A: You can choose T/T, Western union, or you can choose by Alibaba - credit insurance.

Q: Could I visit your factory?

A: Sincerely Invite you to visit our factory

Q: Do you provide samples?

A: Yes, we have material is in stock to help you to get the samples as soon as we can.

Q: What Is the MOQ?

A: 1PC.

Q: Can I get a lower price if I order large quantities?

A: Yes, cheaper prices with more bigger size orders.
