Description

The SmartLine family pressure transmitters are designed around a high performance piezo-resistive sensor. This one sensor integrates multiple sensors linking process pressure measurement with on-board static pressure (DP Models) and temperature compensation measurements. This level of performance allows the ST 700 to replace most competitive transmitters available today.

Unique Indication/Display Option

The ST 700 modular design accommodates a standard alphanumeric LCD display or a unique advanced graphics LCD display with many unparalleled features.

Standard LCD Display Features

• Modular (may be added or removed in the field).

• Supports HART protocol variant.

• 0, 90,180, & 270 degree position adjustments.

• Four configurable screens.

• Standard and custom measurement units available.

• Display calculated flow (square root) value in addition to analog output signal.

• 2 Lines 6 digits PV (9.95H x 4.20W mm) 8 Characters.

• Write protect Indication.

• Built-in Basic Device Configuration through Internal or External Buttons – Range/Engineering Unit/Loop Test /Loop Calibration/Zero /Span Setting.

• Multiple language capabilities (EN, RU).

Advanced Graphics LCD Display Features

• Modular (may be added or removed in the field).

• 0, 90, 180, & 270-degree position adjustments.

• Standard and custom measurement units available.

• Up to eight display screens with 3 formats are possible.

• Large PV with Bar Graph or PV with Trend Graph.

• Configurable screen rotation timing (1 to 30 sec).

• Display calculated flow (square root) value in addition to analog output signal.

• Unique “Health Watch” indication provides instant visibility of diagnostics.

• Multiple language capability (EN, DE, FR, IT, ES, RU, TR, CN, & JP).

Diagnostics

SmartLine transmitters all offer digitally accessible diagnostics which aid in providing advanced warning of possible failure events minimizing unplanned shutdowns, providing lower overall operational costs.

System Integration

• SmartLine communications protocols all meet the most current published standards for HART/DE. • Integration with Honeywell’s Experion PKS offers the following unique advantages.

o Tamper reporting.

o FDM Plant Area Views with Health summaries.

o All ST 700 units are Experion tested to provide the highest level of compatibility assurance.

Configuration Tools

Integral Two Button Configuration Option

Suitable for all electrical and environmental requirements, SmartLine offer the ability to configure the transmitter and display via three externally accessible buttons when either display option is selected. Zero/span capabilities are also optionally available via these buttons with or without selection of a display option.

Handheld Configuration

SmartLine transmitters feature two-way communication and configuration capability between the operator and the transmitter. All Honeywell transmitters are designed and tested for compliance with the offered communication protocols and are designed to operate with any standards compliant handheld configuration device, such as Honeywell Versatilis Configurator.

Personal Computer Configuration

On a personal computer or laptop, Honeywell Field Device Manager (FDM) Software and FDM Express can be used for managing HART device configurations.

Modular Design

To help contain maintenance & inventory costs, all ST 700 transmitters are modular in design supporting the user’s ability to replace meter bodies, add indicators or change electronic modules without affecting overall performance or approval body certifications. Each meter body is uniquely characterized to provide in-tolerance performance over a wide range of application variations in temperature and pressure and due to the Honeywell advanced interface, electronic modules may be swapped with any electronics module without losing in-tolerance performance characteristics.

Modular Features

o Meter body replacement.

o Exchange/replace electronics/comms modules*.

o Add or remove integral indicator*.

o Add or remove lightning protection (terminal connection)*.

* Field replaceable in all electrical environments (including IS) except flameproof without violating agency approvals.

With no performance effects, Honeywell’s unique modularity results in lower inventory needs and lower overall operating costs.
